MLB-SW Mega-Coupler Black w/Steel Wingnut
Can Sub - MLB1/2CS-SW Mega-Coupler 1/2 inch CS Bolt Black SW
ALL BULBS will beat "ALL" competitors pricing! ….... Call 516.766.2266
MLB-SW Mega-Coupler Black w/Steel Wingnut
The Mega-Coupler has a 1/2″ × 1 1/4" Hex Head Bolt with The Light Source Wing Nut.
Our Mega-Coupler has solid nut tabs that won’t break off. It uses standard 1/2 inch by 1-1/4 inch long hex head grade 8 bolts to secure your load. The bolt head locks into the hex milled pocket so that you can tighten the nyloc nut while the clamp is installed. The Mega-Coupler fastens from (1-1/4" Pipe) 1.66" OD to 2 " OD truss tube and has the industry compatible 14 mm thick base.
Mega-Coupler Options -
- 1/2″ × 1 1/4" Hex Head Bolt with Nylock Nut (Standard Mega-Coupler pictured above)
- 1/2" countersunk (CS) flat head bolt (see Mega-Coupler with Flat Head Bolt.)
- 3/8" countersunk (CS) flat head bolt (see Mega-Coupler with Flat Head Bolt)
- 3/8″ × 1″ Hex Head Bolt (3/8)
- 1/2″ × 1 1/4" stainless steel (SS) bolt
- 1/2″ × 1 1/4" steel wingnut (SW)
- Minimum Size
1.25" pipe, 1.66" OD pipe
- Maximum Size
1.5" pipe, 1.90" OD pipe, 2" OD truss tube
- Safe Vertical Working Load
1,100 lb 500kg
- Hardware
Standard hardware -
1/2-13 × 1 1/4" Hex Head grade 8 zinc plated steel bolt with nylock nut
1" Belleville Washer- Weight 1.2 Pounds
- Case Quantities 24
